syrotech 1010 onu

Name: syrotech 1010 onu
Brand: FIBROS TECHNOLOGY
Price: 900.0 INR
Availability: InStock

900.0 INR/Piece

Get a Price/Quote

Product Details:

Frequency Downstream 2.488 Gbps, Upstream 1.244 Gbps
Model Syrotech SY-GPON-1010
Shelf Life N/A (Electronic Device)
Features Single-mode fiber, High speed, Plug-and-play, LED indicators, 1 GE port
Battery Backup No built-in battery backup
Power Supply 12V DC, 0.5A Adapter
Mounting Type Desktop / Wall Mountable
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

syrotech 1010 onu Price And Quantity

Price 900.0 INR/Piece
Minimum Order Quantity 1 Piece

Security AES-128 encryption
Compliance ITU-T G.984.x standard
Ethernet Port 1 x RJ-45 Gigabit Ethernet Port
Max Splitting Ratio 1:128
Storage Temperature -40C to 85C
Typical Power Consumption <3W
Wavelength Tx: 1310 nm, Rx: 1490 nm
Relative Humidity 10% to 90% (non-condensing)
Management OMCI, Web GUI
Optical Port 1 x SC/UPC connector
LED Indicators Power, LOS, PON, LAN
Supported Protocols IPv4, DHCP, PPPoE, Static IP, VLAN tagging
Receiver Sensitivity -28 dBm

syrotech 1010 onu Product Specifications

Battery Backup No built-in battery backup
Features Single-mode fiber, High speed, Plug-and-play, LED indicators, 1 GE port
Dimension (L*W*H) 90mm x 82mm x 24mm
Shelf Life N/A (Electronic Device)
Product Type syrotech 1010 onu
Model Syrotech SY-GPON-1010
Coverage Area Up to 20 km (with compatible OLT)
Frequency Downstream 2.488 Gbps, Upstream 1.244 Gbps
Connectivity Type GPON (Gigabit Passive Optical Network)
Range PON transmission distance up to 20km
Interface Type 1 x 10/100/1000 Mbps RJ45 Ethernet, 1 x SC/UPC PON Port
Size Standard
Operating Temperature -5C to 55C
Capacity Supports up to 128 ONUs per PON port (with OLT)
Mounting Type Desktop / Wall Mountable
Weight 130g
Power Supply 12V DC, 0.5A Adapter
Material Metal
Application Industrial

Security AES-128 encryption
Compliance ITU-T G.984.x standard
Ethernet Port 1 x RJ-45 Gigabit Ethernet Port
Max Splitting Ratio 1:128
Storage Temperature -40C to 85C
Typical Power Consumption <3W
Wavelength Tx: 1310 nm, Rx: 1490 nm
Relative Humidity 10% to 90% (non-condensing)
Management OMCI, Web GUI
Optical Port 1 x SC/UPC connector
LED Indicators Power, LOS, PON, LAN
Supported Protocols IPv4, DHCP, PPPoE, Static IP, VLAN tagging
Receiver Sensitivity -28 dBm

syrotech 1010 onu Trade Information

Supply Ability 5000 Piece Per Month
Delivery Time 7 Days
Main Export Market(s) [, ]
Main Domestic Market [, ]

Product Description

1GE+1POTS XPON HGU terminal devices are designed for fulfilling FTTH and triple play service demand of fixed network operators. This box is based on the mature Chipset (Realtek) technology, which have high speed performance, and the technology of Layer 2/3, and high quality VoIP as well. Support full management of HGU devices through Syrotech OLT. They are highly reliable and easy to maintain, with guaranteed QoS for different service. And they are fully compliant with technical regulations such as ITU-T G.984.x and technical requirement of GPON Equipment from China Telecom.

Robust Connectivity and Fast Performance

The Syrotech 1010 ONU combines a single-mode fiber SC/UPC connector with a gigabit Ethernet port for seamless, high-speed internet access. With GPON technology, it achieves downstream rates of 2.488 Gbps and upstream of 1.244 Gbps-ideal for demanding industrial environments or high-capacity networks.

Easy Installation and Versatile Mounting

Installation is straightforward due to its plug-and-play design. The device offers flexibility with both desktop and wall mounting options. LED indicators provide at-a-glance status updates, making troubleshooting and maintenance efficient for service providers and network admins alike.

Reliable and Secure Operation

Engineered with AES-128 encryption, the Syrotech 1010 ONU keeps data transmissions secure. Its durable metal body endures temperatures from -5C to 55C, while low power consumption (<3W) supports energy efficiency. The unit manages up to 128 ONUs per PON port, making it scalable for growing operations.

FAQ's of syrotech 1010 onu:

Q: How do I install the Syrotech SY-GPON-1010 ONU?

A: Installation is easy-connect the SC/UPC PON port to a single-mode fiber source and plug the RJ-45 Ethernet port into your device or network. Power the unit using the included 12V DC adapter. It supports both desktop and wall mounting for added flexibility.

Q: What are the primary benefits of using this ONU model?

A: The primary advantages include high-speed GPON connectivity, secure AES-128 encrypted data transmissions, plug-and-play usability, and support for up to 128 ONUs per PON port. It's also designed for durability and can operate reliably within industrial environments.

Q: Where can the Syrotech 1010 ONU be deployed?

A: This ONU is ideal for industrial, commercial, and large network deployments across India. Its robust design and 20 km coverage make it suitable for locations requiring long-range, stable, and fast optical internet connections.

Q: What management options are available for this ONU?

A: You can manage the device using OMCI for remote configuration or a web-based GUI for straightforward local administration. LEDs also provide quick visual feedback for power, connection, and status.

Q: What protocols and standards does the Syrotech ONU support?

A: It is compliant with ITU-T G.984.x standards and supports IPv4, DHCP, PPPoE, Static IP, and VLAN tagging for broad network compatibility and efficient data traffic management.

Q: How secure is the data transmission on this device?

A: Data transmissions are protected by AES-128 encryption, ensuring a strong level of security for sensitive information over the optical network.

Q: What environmental conditions can the Syrotech 1010 ONU withstand?

A: The device operates in temperatures between -5C and 55C and tolerates storage from -40C to 85C with 10%-90% non-condensing relative humidity, ensuring reliability in various Indian climates.
