2 Core OFC Cable Double FRP And Double Yarn

2 Core OFC Cable Double FRP And Double Yarn Product Specifications

• Pairs 1 Pair
• Armored Material Double FRP (Fiber Reinforced Plastic)
• Conductor Diameter 5.8 mm
• Jelly Filled No
• Conductor Number 2
• Rip Cord Yes
• Insulation UV Resistant HDPE
• Heat Proof Yes
• No Of Core 2
• Installation Guideline Suitable for overhead and duct installation, can be installed in outdoor environments
• Product Type Double FRP And Double Yarn
• No Of Pairs 1
• Jacket Black LSZH (Low Smoke Zero Halogen) or HDPE
• Color White
• Number of Conductor 2

• Waterproof Yes
• Fiber Type Single Mode
• Outer Diameter ~4.8 mm (approx)
• Tensile Strength Up to 1000 N
• Compliant Standard IEC 60794-1-2
• Operating Temperature Range -20C to +70C
• Minimum Bending Radius 20x Cable Diameter
• Yarn Double Layer Aramid Yarn for additional strength
• Application FTTH (Fiber To The Home), Access Network, Indoor/Outdoor Use
• Cable Shape Round
• Cable Weight Approx 25 kg/km
• Strength Member Double FRP rods
• Crush Resistance Good, suitable for rough handling
